Hardware developed by the BCDA group* |
| Project No. | Description | Documentation | Images | Designer |
|---|---|---|---|---|
| BC-001 | Early transition board prototype | - | - | - |
| BC-002 | Another early transition board | - | - | - |
| BC-003 | Paddle board for use with BC-005 | Versions | image | Kurt Goetze |
| BC-004 | - | - | - | - |
| BC-005 | OMS VME58 to StepPak transition board | User's Manual (pdf) | front/side | Kurt Goetze |
| BC-006 | Mycom microswitch interface (DIN-rail) | Description (pdf) | image | Kurt Goetze |
| BC-007 | Optical isolation board for use with BC-005 | Description | image | Kurt Goetze |
| BC-008 | Optical limit switch display/inverter | - | front, inside | Peter Fuesz |
| BC-009 | Step-Dir / Step-Step converter | - | Kurt Goetze | |
| BC-010 | Acromag 9440 interface | - | top, front | Peter Fuesz |
| BC-011 | NEAT stage interface | - | Peter Fuesz | |
| BC-012 | TTL to RS232 converter | - | Kurt Goetze | |
| BC-013 | Xycom 240 -> QI 2000 adapter | Pinout | top | Peter Fuesz |
| BC-014 | Mirror Lab alarm/status system | - | Kurt Goetze | |
| BC-015 | Turbo gate valve controller | - | image | Kurt Goetze |
| BC-016 | PSS remote shutter interface | Description | top, front | Kurt Goetze |
| BC-017 | Servo amplifier for use with BC-005 | Description | top, bottom, front | Kurt Goetze |
| BC-018 | Sector 1 nitrogen distribution controller | Diagram (jpg) | top, front, back | Peter Fuesz |
| BC-019 | Picomotor connections | - | Kurt Goetze | |
| BC-020 | Multi purpose IP to Lemo interface (DIN-rail) | Description | image | Kurt Goetze |
| BC-021 | IP330 ADC interface (DIN-rail) | Description | image | Kurt Goetze |
| BC-022 | IP-Unidig interface for BC-020 | Description | image | Kurt Goetze |
| BC-023 | IP-Systran DAC interface for BC-020 | Description | image | Kurt Goetze |
| BC-024 | B.O.N.E. box, for electronics prototyping | Description | top | Peter Fuesz |
| BC-025 | Elastic photon discriminator | - | Kurt Goetze | |
| BC-026 | IP330 ADC interface for BC-020 IP-Lemo system | Description | image | Kurt Goetze |
| BC-027 | Xycom 240 - Mad City Labs Nano-Drive | Pinout | top | Kurt Goetze |
| BC-028 | Relay Module Board | - | image | Peter Fuesz |
| BC-029 | VME58-8 front header adapter for BC-005 | - | image | Peter Fuesz |
| BC-030 | VME Digital Waveform Generator | Description | image | Kurt Goetze |
| BC-031 | VME58-8S front header adapter for BC-005 | - | image | Peter Fuesz |
| BC-032 | VME58 front panel connector breakout | - | - | Peter Fuesz |
| BC-033 | M.A.D.-Stepper stand-alone stepper/driver | Description | image | Kurt Goetze |
| BC-034 | BC-005 Step Select (thumbwheel switch) | Description | image | Kurt Goetze |
| BC-035 | Generic motor driver interface | Description | - | Peter Fuesz |
| BC-036 | BIO-CAT Servo Motor Tester | Description | image | Kurt Goetze |
| BC-037 | OMS58 -> driver transition board, cheap -n- EZ | Description | image | Kurt Goetze |
| BC-038 | IP-DAC & IP-ADC BNC Breakout | Description | image | Kurt or Peter |
| BC-039 | Stepper indexer (in progress) | Kurt Goetze | ||
| BC-040 | NIM-R.O.D. (Realtime Output Divider) | Description | image | Kurt Goetze |
| BC-041 | OMS VME58 Limit switch filter | Description | image | Kurt or Peter |
| BC-042 | NIM Lock-In module (in progress) | Kurt Goetze | ||
| BC-043 | E-Brick I/O interface | Kurt Goetze | ||
| BC-044 | OMS PC-104 interface box | Peter Fuesz | ||
| BC-045 | Radiation Monitor multiplexer | Description | Kurt Goetze | |
| BC-046 | NIM Voltage Reference for APD Amplifiers | Description | image | Kurt Goetze |
| BC-047 | Fast shutter driver interface (in development) | Description | Kurt Goetze | |
| BC-048 | 30idb LN2 Filler Control | Kurt Goetze | ||
| BC-049 | sec.26 White/Pink beam slits OMS wiring for prototype Ebrick | Kurt Goetze | ||
| BC-050 | Simple TTL 2-input Multiplexer | Kurt Goetze | ||
| BC-051 | Kohzu driver box for XOR mirror lab | Kurt Goetze | ||
| BC-052 | OMS PC78 Transition board, used in sec.26 Ebricks | Description | image | Kurt Goetze |
| BC-053 | PC104 External Interrupter | David Kline | ||
| BC-054 | FPGA104 DIO64 Daughter Board | Description | image | David Kline |
| BC-055 | HERIX E-Stop System (sec.30) | Kurt Goetze | ||
| BC-056 | TTL to Differential Module | Kurt Goetze | ||
| BC-057 | PC104 FPGA104 Dual-IO22 32-channel Scaler | David Kline | ||
| BC-058 | PC104 FPGA104 Dual-IO22 Digital I/O | David Kline | ||
| BC-059 | S. Ross Generic Digital I/O 16-ch Scaler | Description | image | David Kline |
| BC-060 | OMM / RV1A Interface | Description | image | David Kline |
| BC-061 | Sector 11 Robot Strain Gauge Alarm System | Kurt Goetze | ||
| BC-062 | 32-Channel Joerger Fanout Module | Description | image | Kurt Goetze |
| BC-063 | PC104 Generic Digital I/O (FLEX 10K) | Description | image | David Kline |
| BC-064 | Sector 7 Motor Transition Board | Peter Fuesz | ||
| BC-065 | OMM / PF4 Filter Interface | Description | image | David Kline |
| BC-066 | IP-HYTEC8402 Interface for BC-020 Lemo Breakout | Kurt Goetze | ||
| BC-067 | IP-Octal RS232 to RJ45 Breakout Board | Description | Kurt Goetze | |
| BC-068 | Generic Digital IO Scaler Transition Board | Description | image | David Kline |
| BC-069 | Generic Digital IO LEMO Transition Board | Description | image | David Kline |
| BC-070 | PC104 Horizontal Bus | Description | image | David Kline |
| BC-071 | VME/uCDimm Generic Digital IO | Description | image | David Kline |
| BC-072 | Ebrick DIO / Femto Amplifier Transition Board | David Kline | ||
| BC-073 | PC104 Generic Digital IO (BC-063) / Femto Amplifier Daughter Board | David Kline | ||
| BC-074 | Generic Digital IO Camera Link Transition Board | David Kline | ||
| BC-075 | PC104 Generic Digital IO (BC-063) / 32/16ch Scaler Daughter Board | David Kline | ||
| BC-076 | Altera Cyclone III Development board | Description | image | David Kline |
| BC-077 | BC-076 Generic Digital IO Daughter Board | Description | image | David Kline |
| BC-078 | Ebrick misc. | - | David Kline | |
| BC-079 | Ebrick misc. | - | David Kline | |
| BC-080 | Ebrick misc. | - | David Kline | |
| BC-081 | Ebrick misc. | - | David Kline | |
| BC-082 | Ebrick misc. | - | David Kline | |
| BC-083 | CARS IP-UD inverter daughter board | - | Kurt Goetze | |
| BC-084 | OMS PC78 to CARS KB-mirror controller for HPSynC | - | Kurt Goetze | |
| BC-085 | APD amplifier for sector 3 | - | Kurt Goetze | |
| BC-086 | Quadrature decoder | - | Kurt Goetze | |
| BC-087 | IP-EP201 (softGlue fpga) to Lemo breakout | - | Kurt Goetze | |
| BC-088 | NIM isolation amplifier for PNC | - | Kurt Goetze | |
| BC-089 | DAC128V output current buffer | - | Kurt Goetze | |
| BC-090 | Transition board tester | - | Kurt Goetze | |
| BC-091 | IP-EP201 (softGlue fpga) I/O interface | Description | img1, img2 | Kurt Goetze |
| BC-092 | IP-EP201 (softGlue fpga) ribbon cable adapter | Description | image | Kurt Goetze |
| BC-093 | OMS Pro-Dex MAXv VME P2 paddle board | Description | image | Kurt Goetze |
* much of this hardware was developed with the help/ideas/inspiration from many people outside the BCDA group, including CAT members and ASD/Controls folks. Thanks!
